Parts of Sensorbee Modbus Lite


The Sensorbee Modbus Lite is composed of two main parts: a base (6) that contains the main board, cable glance (3), sensor dome (2), and status LED (5), and a sensor-house (4) that contains the particle sensor (1).
Image without caption
  1. Particle sensor (PM1, PM2.5, and PM10)
  1. The sensor dome includes sensors for temperature, humidity, and ambient noise (SB3380).
  1. Cable glance for external cabling, RS-485 and power.
  1. Sensor-House, which contains the particle sensor.
  1. Status LED, which indicates the status of the unit.
  1. Base, which contains the base board electronics, internal connectors.
