Parts of Sensorbee Air Lite


The Sensorbee Air Lite is composed of two main parts: a base (6) that contains the main board, internal battery, external connector (3), sensor dome (2), and status LED (5), and a sensor-house (4) that contains the particle sensor (1), see figure 1.
Image without caption
  1. Particle sensor (PM1, PM2.5, and PM10)
  1. The sensor dome includes sensors for temperature, humidity, and ambient noise (SB3380).
  1. Power connector, M8M-4 (type A), for input power to the unit (5VDC to 15VDC).
  1. Sensor-House, which contains the particle sensor.
  1. Status LED, which indicates the status of the unit.
  1. Base, which contains the base board electronics, batteries, internal connectors, and antenna.
